embsys GSM Modem Quectel 95

The embsys GSM Modem Quectel M95 is a compact and reliable quad-band GSM/GPRS communication module designed to provide wireless voice, SMS, and data connectivity for embedded systems, IoT devices, industrial automation, and remote monitoring applications. Built around the Quectel M95 GSM/GPRS module, this modem enables microcontrollers, development boards, and industrial controllers to communicate over 2G cellular networks. It supports 850/900/1800/1900 MHz GSM frequency bands, allowing it to operate in most GSM networks worldwide where 2G service is available. The modem communicates with host devices through a UART serial interface using standard AT commands, making it easy to interface with platforms such as Arduino, Raspberry Pi, ESP32, ESP8266, PIC, AVR, STM32, and other microcontrollers.

The embsys GSM Modem Quectel M95 supports SMS messaging, voice calling, GPRS packet data, TCP/IP, UDP, HTTP, FTP, and MQTT communication (depending on firmware and application), making it suitable for IoT and machine-to-machine (M2M) communication. It also supports caller identification, DTMF detection, real-time clock (RTC), SIM card interface, and network status monitoring. The modem typically includes onboard voltage regulation, antenna connector, SIM card holder, status LEDs, and serial communication pins for simple integration into embedded applications.

The modem operates from a suitable DC power supply and requires a valid GSM SIM card with an active mobile network connection. Once powered, it registers with the GSM network and can send or receive SMS messages, make voice calls, or transmit data over the cellular network. Developers can control all modem functions through simple AT commands, allowing easy integration into automation systems and wireless communication projects.

Specifications

• Module: Quectel M95 GSM/GPRS Module

• Communication Technology: GSM/GPRS (2G)

• Frequency Bands: 850/900/1800/1900 MHz Quad Band

• Network Support: GSM Phase 2/2+

• Communication Interface: UART Serial

• Command Set: Standard AT Commands

• SIM Card Support: Standard GSM SIM Card

• Data Services: GPRS Class 10

• SMS Support: Text Mode and PDU Mode

• Voice Support: Yes

• Antenna Interface: External GSM Antenna

• Operating Voltage: Module-dependent (typically 5V input with onboard regulation or 3.8–4.2V for the module itself)

Features

• Quad-band GSM/GPRS operation

• Supports SMS, voice calls, and GPRS data

• Standard UART serial communication

• AT command-based programming

• Built-in TCP/IP protocol stack

• Low power consumption

• Compact and lightweight design

• Easy integration with microcontrollers

• External antenna support for improved signal reception

• Stable and reliable wireless communication

Applications

The embsys GSM Modem Quectel M95 is widely used in:

• Internet of Things (IoT) devices

• Machine-to-Machine (M2M) communication

• Home automation systems

• Industrial automation

• Remote monitoring systems

• Smart agriculture

• Vehicle tracking systems

• GPS tracking devices

• Wireless sensor networks

• Smart energy meters

• Security and alarm systems

• Remote data logging

• Vending machines

• POS terminals

• Embedded system development

• Educational and engineering projects

Advantages

• Reliable GSM communication

• Easy serial interface with microcontrollers

• Worldwide quad-band network compatibility

• Supports both voice and data services

• Simple programming using AT commands

• Compact design for embedded applications

• Low power operation

• Suitable for long-term industrial deployment

Note: The Quectel M95 operates on 2G GSM networks. Before purchasing or deploying this modem, verify that 2G cellular service is still available in your country or region, as many mobile operators have phased out or are in the process of shutting down 2G networks.

The embsys GSM Modem Quectel M95 is an excellent communication solution for engineers, developers, students, and IoT professionals who require reliable GSM-based wireless connectivity for remote monitoring, automation, telemetry, SMS alerts, voice communication, and embedded cellular applications. Its robust performance, AT command support, and compatibility with popular development platforms make it a trusted choice for a wide range of industrial and IoT projects.
