10pF 50V Capacitor (5 Pcs)

The 10pF 50V Capacitor (5 Pcs) is a small-value, non-polarized capacitor designed for high-frequency electronic applications. It is commonly used in circuits where precise capacitance control is required, especially in RF (radio frequency) systems, oscillators, tuning circuits, and signal coupling applications.

A capacitor is an electronic component that stores and releases electrical energy in an electric field. In this case, the very small capacitance value of 10 picofarads (10pF) allows it to handle fast-changing signals efficiently, making it ideal for high-frequency and precision circuits where larger capacitors would not perform effectively.

The 50V rating indicates the maximum voltage the capacitor can safely handle. It ensures stable operation in low-voltage electronic circuits without breakdown or damage. Since it is a non-polarized capacitor, it can be connected in either direction in the circuit, which makes it easy to use in AC and high-frequency signal applications.

This capacitor is widely used in RF circuits, oscillators, filters, tuning stages, communication devices, and signal processing circuits. It helps in stabilizing frequencies, removing noise, and improving signal accuracy in sensitive electronic systems.

The pack includes 5 identical capacitors, making it suitable for prototyping, repairs, and multiple circuit designs. Its compact size allows easy installation on PCBs and breadboards.

Working Principle

The capacitor works based on the principle of electric charge storage:

• When voltage is applied, it stores electrical energy in an electric field.

• When the voltage drops, it releases the stored energy back into the circuit.

• In AC circuits, it continuously charges and discharges.

• At high frequencies, it helps in filtering and tuning signals.

Because of its very small capacitance value, it responds quickly to rapid signal changes, making it ideal for RF applications.

Key Features

• Capacitance: 10pF (picofarads)

• Voltage rating: 50V

• Non-polarized type

• Suitable for high-frequency circuits

• Ideal for RF and tuning applications

• Stable and reliable performance

• Compact design for PCB use

• Pack of 5 pieces

Applications

The 10pF Capacitor is widely used in:

• RF circuits

• Oscillator circuits

• Tuning circuits

• Signal coupling applications

• Communication devices

• Filters and frequency control circuits

• Arduino and embedded systems

• DIY electronics projects

• Radio and transmitter circuits

• High-frequency signal processing

Specifications

• Product Type: Ceramic/Non-polarized Capacitor

• Capacitance: 10pF

• Voltage Rating: 50V

• Quantity: 5 Pieces Pack

• Mounting Type: Through-hole

• Tolerance: Typically ±5% (standard)

Package Includes

• 5 × 10pF 50V Capacitors

Safety Precautions

• Do not exceed rated voltage (50V).

• Avoid mechanical stress during handling.

• Ensure correct placement in sensitive RF circuits.

• Keep away from excessive heat during soldering.

• Store in a dry, static-free environment.
